Raspberry Pi
Raspberry Pi 5
Raspberry Pi 5
Couldn't load pickup availability
The Raspberry Pi 5 delivers desktop-class performance in a compact single-board computer, featuring a 2.4GHz quad-core ARM processor and 4GB of LPDDR5 RAM. This versatile platform excels for embedded projects, IoT applications, educational robotics, and media centers. With dual 4K HDMI outputs, Gigabit Ethernet, and multiple USB 3.0 ports, it handles demanding workloads while maintaining energy efficiency. The improved thermal design ensures sustained performance during intensive tasks. Compatible with Raspberry Pi OS and various Linux distributions, it provides developers and enthusiasts with a powerful foundation for innovation and experimentation.
Raspberry Pi 5 features the Broadcom BCM2712 quad-core Arm Cortex A76 processor @ 2.4GHz, making it up to three times faster than the previous generation. With RAM variants up to 16GB, this is the fastest, smoothest Raspberry Pi experience yet.
What’s Included
What’s Included
- Raspberry Pi 5 Board only
Technical Specs
Technical Specs
- Broadcom BCM2712 2.4GHz quad-core 64-bit Arm Cortex-A76 CPU, with cryptography extensions, 512KB per-core L2 caches and a 2MB shared L3 cache
- VideoCore VII GPU, supporting OpenGL ES 3.1, Vulkan 1.3
- Dual 4Kp60 HDMI® display output with HDR support
- 4Kp60 HEVC decoder
- LPDDR4X-4267 SDRAM (1GB, 2GB, 4GB, 8GB, and 16GB)
- Dual-band 802.11ac Wi-Fi®
- Bluetooth 5.0 / Bluetooth Low Energy (BLE)
- microSD card slot, with support for high-speed SDR104 mode
- 2 × USB 3.0 ports, supporting simultaneous 5Gbps operation
- 2 × USB 2.0 ports
- Gigabit Ethernet, with PoE+ support (requires separate PoE+ HAT)
- 2 × 4-lane MIPI camera/display transceivers
- PCIe 2.0 x1 interface for fast peripherals (requires separate M.2 HAT or other adapter)
- 5V/5A DC power via USB-C, with Power Delivery support
- Raspberry Pi standard 40-pin header
- Real-time clock (RTC), powered from external battery
- Power button
FAQ
FAQ
Will older versions of Raspberry Pi OS work with Raspberry Pi 5?
The current version of Raspberry Pi OS, Trixie, and the legacy version, Bookworm, work with Raspberry Pi 5. Versions older than Bookworm do not.
Will my Raspberry Pi 4 power supply work with Raspberry Pi 5?
Raspberry Pi 5 is a higher-performance computer than Raspberry Pi 4, and you may have problems using an under-powered supply. We recommend a high-quality 5V 5A USB-C power supply, such as the new Raspberry Pi 27W USB-C Power Supply.
Will my Raspberry Pi 5 fit my Raspberry Pi 4 case?
Raspberry Pi 5 won't fit the Raspberry Pi 4 Case. We recommend the Raspberry Pi Case for Raspberry Pi 5, designed to help you get the most out of our newest computer.
Does Raspberry Pi 5 need active cooling?
Raspberry Pi 5 is faster and more powerful than prior-generation Raspberry Pis, and like most general-purpose computers, it will perform best with active cooling. The Raspberry Pi Case for Raspberry Pi 5, with its integrated fan, is one way to provide this.
